- Original title: Basic Evented Alchemy Gathering using tile swaps
- Original author: Quailar
- Original date: March 21, 2015
- Source thread: https://forums.rpgmakerweb.com/threads/basic-evented-alchemy-gathering-using-tile-swaps.38041/
- Source forum path: Game Development Engines > RPG Maker Tutorials > RMVXAce Tutorials
Summary
Basic Evented Alchemy Gathering I was searching for a way to create a harvest/gather system for alchemy or cooking. I wanted a system that didnt use events to create items for harvest. By using Terrain tags and tile layer Ids, you can place as many harvesting items you want n a map without using an event for each. You will need this game extension here or in demo:
Archived First Post
Basic Evented Alchemy Gathering
I was searching for a way to create a harvest/gather system for alchemy or cooking. I wanted a system that didnt use events to create items for harvest.
By using Terrain tags and tile layer Ids, you can place as many harvesting items you want n a map without using an event for each.
You will need this game extension here or in demo:
http://forums.rpgmakerweb.com/index.php?/topic/25040-ace-useful-script-call-reference/
No tutorial, should be fairly simple demo.
Setup:
1 - Parallel
1- Common Event
Label all tileset items to be used for harvesting with Terrain tag #
You will need to know your tile layers by ID# for swap(using XS-Variable HUD is a great easy way to get them)
Press Enter When over item for harvest
Features:
Unlimited number of harvestabe items.
No map events required
Uses tile swaps
Demo:
http://s000.tinyupload.com/?file_id=10899988343447240067
Protected downloadProtected downloadProtected download
I was searching for a way to create a harvest/gather system for alchemy or cooking. I wanted a system that didnt use events to create items for harvest.
By using Terrain tags and tile layer Ids, you can place as many harvesting items you want n a map without using an event for each.
You will need this game extension here or in demo:
http://forums.rpgmakerweb.com/index.php?/topic/25040-ace-useful-script-call-reference/
#--------------------------------------------------------------------------
#Modifications
#--------------------------------------------------------------------------
#Changed Line 88 in Game_Event
#from
# if near_the_screen? && @stop_count > stop_count_threshold
#to
# if @stop_count > stop_count_threshold
#--------------------------------------------------------------------------
# REGION MANIPULATION
#--------------------------------------------------------------------------
class Game_Map
def setTileRegion(reg_x,reg_y,reg_id)
if reg_id > 63 || reg_id < 0
reg_id = 0
end
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
@bLEFT = "%6b" % reg_id
@newvalue = @bLEFT.to_s + @bRIGHT.to_s
@newvalue = @newvalue.to_i(2)
self.data[reg_x, reg_y, 3] = @newvalue
end
def getTileRegion(reg_x,reg_y)
# gets a 14 bit long binary string from the map data array
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
# converts the binary string back to an integer and returns
return(@bLEFT.to_i(2))
end
def getTileShadowID(reg_x,reg_y)
# gets a 14 bit long binary string from the map data array
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# returns binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
# converts the binary string back to an integer and returns
return(@bRIGHT.to_i(2))
end
#--------------------------------------------------------------------------
# MAP MANIPULATION
#--------------------------------------------------------------------------
def getTileIDByLayer(x,y,layer)
return(self.data[x,y,layer])
end
def setTileIDByLayer(x,y,layer,tile_ID)
self.data[x,y,layer] = tile_ID
end
end
#--------------------------------------------------------------------------
# Save Tile Manipulation
#--------------------------------------------------------------------------
class Game_System
def changeTileByInternalID(map_id,x,y,layer,intID)
initialize_pos_list(map_id, layer)
tid = intID
@swapped_pos_tiles[map_id][layer][y] = [] if @swapped_pos_tiles[map_id][layer][y].nil?
@swapped_pos_tiles[map_id][layer][y][x] = tid
$game_map.load_new_map_data
end
end
#--------------------------------------------------------------------------
# Battler Additions
#--------------------------------------------------------------------------
class Game_Battler < Game_BattlerBase
def wtype_equipped?(wtype_id)
return weapons.any? {|weapon| weapon.wtype_id == wtype_id }
end
def atype_equipped?(atype_id)
return armors.any? {|armor| armor.atype_id == atype_id}
end
end
#Modifications
#--------------------------------------------------------------------------
#Changed Line 88 in Game_Event
#from
# if near_the_screen? && @stop_count > stop_count_threshold
#to
# if @stop_count > stop_count_threshold
#--------------------------------------------------------------------------
# REGION MANIPULATION
#--------------------------------------------------------------------------
class Game_Map
def setTileRegion(reg_x,reg_y,reg_id)
if reg_id > 63 || reg_id < 0
reg_id = 0
end
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
@bLEFT = "%6b" % reg_id
@newvalue = @bLEFT.to_s + @bRIGHT.to_s
@newvalue = @newvalue.to_i(2)
self.data[reg_x, reg_y, 3] = @newvalue
end
def getTileRegion(reg_x,reg_y)
# gets a 14 bit long binary string from the map data array
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
# converts the binary string back to an integer and returns
return(@bLEFT.to_i(2))
end
def getTileShadowID(reg_x,reg_y)
# gets a 14 bit long binary string from the map data array
@thirdvalue = "%14b" % self.data[reg_x, reg_y, 3]
# returns binary split of the two elements
@bLEFT = @thirdvalue[0,6] # REGION ID IN BINARY
@bRIGHT = @thirdvalue[6,8] # SHADOW ID IN BINARY
# converts the binary string back to an integer and returns
return(@bRIGHT.to_i(2))
end
#--------------------------------------------------------------------------
# MAP MANIPULATION
#--------------------------------------------------------------------------
def getTileIDByLayer(x,y,layer)
return(self.data[x,y,layer])
end
def setTileIDByLayer(x,y,layer,tile_ID)
self.data[x,y,layer] = tile_ID
end
end
#--------------------------------------------------------------------------
# Save Tile Manipulation
#--------------------------------------------------------------------------
class Game_System
def changeTileByInternalID(map_id,x,y,layer,intID)
initialize_pos_list(map_id, layer)
tid = intID
@swapped_pos_tiles[map_id][layer][y] = [] if @swapped_pos_tiles[map_id][layer][y].nil?
@swapped_pos_tiles[map_id][layer][y][x] = tid
$game_map.load_new_map_data
end
end
#--------------------------------------------------------------------------
# Battler Additions
#--------------------------------------------------------------------------
class Game_Battler < Game_BattlerBase
def wtype_equipped?(wtype_id)
return weapons.any? {|weapon| weapon.wtype_id == wtype_id }
end
def atype_equipped?(atype_id)
return armors.any? {|armor| armor.atype_id == atype_id}
end
end
No tutorial, should be fairly simple demo.
Setup:
1 - Parallel
1- Common Event
Label all tileset items to be used for harvesting with Terrain tag #
You will need to know your tile layers by ID# for swap(using XS-Variable HUD is a great easy way to get them)
Press Enter When over item for harvest
Features:
Unlimited number of harvestabe items.
No map events required
Uses tile swaps
Demo:
http://s000.tinyupload.com/?file_id=10899988343447240067
Protected downloadProtected downloadProtected download
Features Mentioned
- Unlimited number of harvestabe items.
- No map events required
- Uses tile swaps
- Demo:
